BMD-D
Service Multi-Deck Dry
Hillphoenix BMD-D Multi-Deck, Dry Service Case. Designed for deli or bakery applications with up to two rows of shelves for merchandising. Available in various lengths with flat or curved, lift glass profiles. Front profile lines up with the BMD-R Bakery, BMD-R Deli, BMDH and BMD-RG.
Hillphoenix BMD-D Multi-Deck, Dry Service Case. Designed for deli or bakery applications with up to two rows of shelves for merchandising. Available in various lengths with flat or curved, lift glass profiles. Front profile lines up with the BMD-R Bakery, BMD-R Deli, BMDH and BMD-RG.
Please consult Hillphoenix Engineering Reference Manual for dimensions, plan views and technical specifications. Specifications subject to change without notice. Designed for optimal performance in store environments where temperature and humidity do not exceed 75°F and 55% R.H. Certified to UL 471, ANSI/NSF Standard 2,7,51 and CAN/CSA C22.2.
Service Multi-Deck Dry
Hillphoenix BMD-D Multi-Deck, Dry Service Case. Designed for deli or bakery applications with up to two rows of shelves for merchandising. Available in various lengths with flat or curved, lift glass profiles. Front profile lines up with the BMD-R Bakery, BMD-R Deli, BMDH and BMD-RG.
Hillphoenix BMD-D Multi-Deck, Dry Service Case. Designed for deli or bakery applications with up to two rows of shelves for merchandising. Available in various lengths with flat or curved, lift glass profiles. Front profile lines up with the BMD-R Bakery, BMD-R Deli, BMDH and BMD-RG.
Features & Benefits
- Sled-runner base construction.
- Painted metal exterior.
- Standard 51-1/8"H with 7-13/16"H toe kick height.
- Standard 44" depth.
- 45 Degree front die board.
- Stainless steel exterior trim.
- Stainless steel front, side and rear base trim.
- Outside back and case top painted to match exterior.
- Black painted metal interior.
- Interior trim to match interior.
- Reflective rear load doors with black frames.
- Single-pane, regular-glare, flat lift front glass.
- Black painted metal flat bottom merchandising deck.
- Clearvoyant LED dual top lighting.
- Rear electrical raceway.
- Solar digital thermometer.
- Energy efficient fans.
- Hard wired on site by others.
Available Options
- Available lengths: 4’, 6’, 8’, 10’, and 12’.
- Case heights available: 48” and 54”.
- Altermate 6-5/16”H toekick height.
- Flat front profile.
- Bullet Leg base with adjustable height toekick.
- Pedestal base or false pedestal.
- Painted metal base trim.
- Cart bumper.
- Interior and exterior stainless steel finish.
- White or other painted metal interior finish.
- Painted metal, solid surface or stone case top.
- Scale stand: Poly, SS, solid surface or stone.
- Prep to accommodate lighted shelving for future addition.
- (1)row (1) 12” metal shelving with PTM on 48”H.
- (2)rows (1) 10” and (1) 14” metal shelving with PTM on 51”H.
- (3)rows (1) 8”, (1) 14” and (1) 16” black painted metal shelving with PTM on 54”H.
- Shelving types: Glass, painted metal, or SS.
- Clear rear load doors.
- Rear fixed or flip-up work boards: Poly, SS, solid surface.
- Front electrical raceway.
- ISO outlet/CON outlets or CAT 5.
- Solid interior mirror polish stainless steel, thermal glass divider or glass ends.
- Vertical rear struts for bakery application.
Attributes
- Alternate Heights: 48-1/8" or 54-1/8"
- Case Depth / Footprint: 44"
- Case Height Standard: 51-1/8"
- Case Length: 4’, 6’, 8’, 10', and 12
- Case Temp: Dry Foods
- Case Type: Multi-Deck, Service, Rear-Load
- Department: Bakery, Deli
- Door Type: -
- Interior Depth: 31-3/8"
- Interior Height: 15-13/16"
- Other Models: BMD-R, BLF series, SMD-R Bakery, SMD-R Deli
- Product Type: Specialty Cases
- Refrigerated Volume: -
- Remote / Self-Contained: Dry
- Retail Types: Food Service, Mass Merchandise, Membership & Warehouse, Supermarket
